Why Choose the FG-TIKAL magnetic strainer ?
Using DN65 magnetic filters in boiler rooms and heating or cooling circuits offers numerous benefits, significantly enhancing the performance and efficiency of industrial systems. These filters effectively separate suspended particles and deposits from the water flow, preventing their accumulation in sensitive equipment such as pumps, heat exchangers, and boilers.
This process extends the service life of the equipment and reduces the need for frequent repairs, directly lowering maintenance and operational costs. Additionally, by optimizing water flow and minimizing pressure drop, system efficiency improves, leading to a noticeable reduction in energy consumption.
|
c(mm) |
b(mm) |
a(mm) |
مدل |
|---|---|---|---|
|
220 |
230 |
270 |
dn50 |
|
220 |
290 |
270 |
dn65 |
|
285 |
310 |
320 |
dn80 |
|
285 |
340 |
360 |
dn100 |
|
335 |
400 |
414 |
dn125 |
|
390 |
480 |
540 |
dn150 |
|
460 |
600 |
650 |
dn200 |
|
570 |
730 |
700 |
dn250 |
|
750 |
850 |
800 |
dn300 |
جدول سایز بندی F-TIKAL
Key Features of the F-TIKAL DN65 magnetic strainer
Durable Body Construction: Made from ST52 steel with a hot-dip galvanized protective layer and triple-layer epoxy coating, ensuring superior resistance to corrosion and rust.
Flanged Connections: Facilitates easy installation and setup with standardized flanged fittings.
High Magnetic Strength: Equipped with 4 to 10 powerful magnetic rods, each 25 to 35 cm in length, for efficient sediment separation.
Easy Maintenance: Semi-automatic sediment separation eliminates the need for part replacements, simplifying routine maintenance.
Wide Temperature Range: Operates effectively in temperatures from 1°C to 85°C.
Stainless Steel Strainer: Includes an L304 stainless steel strainer for enhanced durability and filtration performance.
Standardized Design: Flanges are designed to meet PN standards and can handle working pressure up to PN16.
Reduced Pressure Drop: Achieves a 50% reduction in pressure drop compared to conventional Y-strainers.
Reinforced Body: Steel body coated with anti-corrosion static paint for long-lasting strength and reliability.
Drain and Air Vent Ports: Equipped with dedicated ports for drainage and air venting to streamline maintenance.
Available in Multiple Sizes: Offered in sizes ranging from DN50 to DN300, catering to various industrial applications.
2-Year Warranty: Backed by an unconditional 2-year warranty for peace of mind and reliable performance.
